Setup & Tuning:
Java based configuration software is powerful and
intuitive. Comprehensive diagnostics, auto-tuning and
advanced oscilloscope tools simplify system commissioning.
Auto-phasing eliminates time consuming rewire-and-try
for encoder/Halls/motor connections. Set-up software
automatically compensates for crossed wires eliminating the most
common cause of startup headaches.
Point-and-click to define 0 to 32 indexes or index sequences.
Simply select the index/sequence and command GO. Index
sequences can include parameter changes, dwell times
and I/O control. Any parameter can be assigned to a register
for efficient control by a PLC.
Custom functions can be provided for complex applications.
Install the Java "bean" and fill in the blanks. Copley also
provides a flexible OEM programming environment. Copley
Virtual Machine assembler/debugger enables the development
of fast, compact control programs.
Built-In CAM Tables:
Camming is an effective way to produce repetitive motion
synchronized to an external device. A pre-defined cam-table
of slave positions is typically cycled through by a master
encoder connected to the drive. The drive performs linear
interpolation between points to minimize cam-table size.
