linear motors Key Features:

Small profile linear motors
Short moving part
Steel core for high force density
LO-COG for smooth motion
Built-in thermal sensors
Hall-effect sensors
Water cooling option
Modular magnet track for unlimited travel
  Magnets covered by stainless steel strip

  Request catalog

linear motors

Iron core LC (LO-COG) Series linear motors are designed to provide a lower cost and lower profile alternatives to conventional linear motor applications.  Unlike conventional iron core motors, LC motors feature very low cogging force (0.5%) which make them suitable to replace core-less  motors, providing much higher power densities. The moving forcer coil assembly contains Hall-effect and thermal sensors in a compact structure. LC linear motors also feature smaller attraction forces as compared to conventional iron core motors. These motors are ideal in applications requiring high level of positioning resolution and accuracy. Magnet tracks are stackable for any travel length. LC linear motors are suitable for clean room applications as they produce no particles.



Motor

Model

Forcer

Length

LM

(mm)

Forcer

Width

WM

(mm)



Motor

Height

H

(mm)



Magnet

Way Length

LW

(mm)

Magnet

Way Width

WW

(mm



RMS

Force

no cooling

(N)

RMS

Force

water cooling

(N)



Peak

Force

(N)

Forcer

Weight

(kg)

LC-100-25 110 55





37



144



240



336



384

30/50 60 100 160 0.75
LC-100-50 110 80 55/75 110 200 320 1.0
LC-200-25 206 55 30/50 115 200 320 1.4
LC-200-50 206 80 55/75 220 400 650 2.0
LC-300-50 302 80 55/75 340 580 1000 3.0
LC-300-75 301 105 80/100 500 900 1500 4.5



linear motors

LC forcer shown installed with linear guides
