gantry
gantry          Key Features:


Turn-key solution
Modular design
Direct linear drive
High speed and acceleration
Zero backlash
Fast settling time
Large travel area







Click HERE to enter new IntelLiDrives website www.intellidrives.com



XYZ Gantry Robotics offer significant advantages over robotic arms for high speed automation



  • larger work envelopes

  • open frame and overhead systems

  • larger payloads


  • These gantry robotics systems are integrated with Linear Servo Slide direct drives which are offered in three frame sizes: small (LSS90), medium (LSS120)  and wide (LSS200) with work area from 500 x 500 mm up to 2000 x 3000 mm and payloads up to 200 Kg. These systems have all cable tracks (including user connections) installed for quick disconnect. All robotics axes are aligned and pinned so that axes may be removed and re-attached with original precision.



    Gantry specifications:



    travel area (X x Y x Z mm): 3000 x 2000 x 200

    thrust force (N): 250 (LSS90), 450 N (LSS120), 1200 (LSS200)

    repeatability (microns): 10 - 50

    resolution (microns): 0.5 - 25

    max velocity (m/sec): 2

    payload (kg): 200
