robotic arm

Key Features:


Turn-key solution
Modular design
Direct linear drive
High speed and acceleration
Zero backlash
Fast settling time
Large travel area





Request catalog





IntelLiDrives XYZ multi-axes robotic arm systems are pre-engineered turn-key solutions designed to optimize workspace, simplify selection, and lower cost. These systems are integrated with Linear Servo Slide direct drives which are offered in three frame sizes sizes: small (LSS90), medium (LSS120)  and wide (LSS200) with work area from 200 x 200 mm up to 1000 x 2000 mm and payloads up to 25 Kg. These systems have all cable tracks (including user connections) installed for quick disconnect. All axes are aligned and pinned so that axes may be removed and re-attached with original precision.



 General Specifications:



travel area (X x Y x Z mm): 1200 x 800 x 200

thrust force (N): 250 (LSS90), 450 (LSS120), 1200 (LSS200)

repeatability (microns): 10 - 50

resolution (microns): 0.5 - 25

max velocity (m/sec): 2

payload (kg): 25








Configurations



robotic arm



robotic arm

Stacked XY robotic arm

 (moving slider)



Stacked XY robotic arm

(moving arm)





  Double arm XY System



XZ robotic arm  (elevator)   XZ robotic arm (moving slider/arm)
